Description:
The Vapor-D features a DC structure that evolves from the Wide X version.
It delivers exceptional flight performance with the TAKER H60_BLS 60A 4-in-1 ESC and GEP-F722-HD V2 flight controller. Its unique DC design ensures the camera does not capture the propellers in view, boosting both video quality and flight enjoyment. With sleek CNC aluminum alloy side panels, the Vapor-D offers a perfect blend of style and strength.
Available in both 5-inch and 6-inch models, it's made fo every pilot and every flying need
Feature:
- The DC structure, paired with the TAKER H60_BLS 60A 4-in-1 ESC and GEP-F722-HD V2 FC, ensures stable flight and excellent shooting.
- Boost maneuverability and power for stunning aerial footage with GEPRC SPEEDX2 E-series motors.
- The sleek side panels, crafted from CNC aluminum alloy, provide stylish yet sturdy protection for the camera.
- The front lens guard provides reliable protection during flights.
- The DC structure enhances both shooting quality and flying fun.
- Choose between 5-inch and 6-inch models to fit your flying preferences.
Specifications:
Brand: GEPRC
Model: Vapor D5 Analog
Item Name: 5 Inch 6S Freestyle FPV Drone
GPS: Geprc GEP M10 GPS
Model: | Vapor D5 Analog | Vapor D6 Analog | ||||
Version | Vapor D5 DJI O3 Air Unit | Vapor D5 Wasp | Vapor D5 Analog | Vapor D6 DJI O3 Air Unit | Vapor D6 Wasp | Vapor D6 Analog |
VTX | DJI O3 Air Unit | Link | MATEN 5.8G 1.6W VTX | DJI O3 Air Unit | Link | MATEN 5.8G 1.6W VTX |
Camera | DJI O3 Camera | Wasp | Caddx H1 | DJI O3 Camera | Wasp | Caddx H1 |
Antenna | 5.8G&2.4G | Momoda2 5.8G Antenna LHCP SMA 90mm | Momoda2 5.8G Antenna LHCP SMA 90mm | 5.8G&2.4G | Momoda2 5.8G Antenna LHCP SMA 90mm | Momoda2 5.8G Antenna RHCP SMA 90mm |
Weight | 435g±5g | 428±5g | 428±5g | 467g±5g | 459±5g | 460g±5g |
Motors | GEPRC SPEEDX2 2207E 1960 KV | GEPRC SPEEDX2 2407E 1750KV | ||||
Propellers | GEMFAN 5136 | HQ 6X3.5X3 | ||||
Frame | Vapor-D5 frame | Vapor-D6 frame | ||||
Wheelbase | 238.43mm | 274.60mm | ||||
Flight Time | 13min (1550mah) | 17min (1800mah) | ||||
Top Plate | 2.0 mm | |||||
Middle Plate | 2.0mm | |||||
Bottom Plate | 2.5 mm | |||||
Arm Thickness | 5.0 mm | |||||
FC | GEP-F722-HD v2 | |||||
MCU | STM32F722 | |||||
Gyro | ICM42688-P(SPI) | |||||
OSD | Betaflight OSD w/AT7456E | |||||
ESC | TAKER H60_BLS 60A 4IN1 ESC | |||||
Connector | XT60 | |||||
Receiver | PNP/GEPRC ELRS24/TBS Nano RX | |||||
Recommended Battery | 6S LiPo1550mAh - 2200mAh | |||||
Optional GPS | GEP-M10 GPS |
Package Included:
1 x Vapor D5 Analog
2 x GEMFAN 5136
2 x Battery Anti-Slip Pads
1 x Spare Screw Pack
2 x M20*250mm Battery Straps
1 x L-shaped Screwdriver 1.5mm
1 x L-shaped Screwdriver 2.0mm
1 x GPro Mount
